Ideal for both residential and commercial applications, it ensures uninterrupted power supply with advanced technology and robust build quality.
| Product | Battery Control Unit (BCU) |
| System Working Voltage Range | 200~870V |
| System Working Current | 50A |
| Monitoring Communication | RS232 |
| Battery Communication | CAN, RS485 |
| External Communication | CAN, RS485, Dry Contact, WiFi |
| Self-consumption Power | 7.56W |
| Dimensions | (W*D*H) 484*510*140mm / 19.1*20.1*5.5 inch |
| Weight | 13.3 kg / 29.3 lbs |
| Protection Rate | IP20 |
| WIFI Module | RF Band Range: 2.412GHz-2.472GHz |
| Transmit power 802.11b: +17 +/-1.5dBm(@11Mbps)； 802.11g: +15+/-1.5dBm(@54Mbps)； 802.11n: +14+/-1.5dBm(@HT20, MCS7) |
|
| Antenna Type: External WIFI Sticker, I-PEX to SMA 3dBi |
|
| Gain: 3dBi |
| Product | Battery Module Unit (BMU) |
| Cell Type | LFP |
| Nominal Energy | 5.12 kwh |
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 100 Ah |
| Continuous Operation Current | 50 A |
| Voltage Range | 45.5-58V |
| Expansion | 5-15 pcs |
| Depth of Discharge | 90% |
| Dimensions (W*D*H) | 484*530*140 mm / 19.1*20.9*5.5 inch |
| Weight | 43 kg / 94.8 lbs |
| Cycle Life | ≥6000 cycles |
| Operation Temperature | Charge：0°C~45°C(32°F~113°F)， Discharge: -10°C~50°C(14°F~122°F) |
| Storage Temperature | Within 1month: -20°C~50°C(-4°F~122°F) 1-3months: -10°C~40°C(14°F~104°F) 3-12months: > 0°C~30°C(32°F~86°F) |
| Protection level | IP20 |
| Certifications | CE, IEC62619, UL1973, UL9540, UL9540A, UN38.3 |
